External Bio Digital Wall Mounted Controller - BD7012

Specifications of External Bio Digital Wall Mounted Controller - BD7012

Model:

BD7011

Operation:

Touchpad - Touch Control

Rated Voltage:

220-240V ~ 1 N PE (EU model)

Switching Power in Finnish Mode:

Max 9.0KW for Fin-sauna heater

Switching Power in Humidity Mode:

Maximum 9.0 kW plus 1.5 kW for the bio vaporator unit

Control Range for Finnish Mode:

5° to 110° Celsius - 5 adjustment

Control Range for Bio Mode:

5° to 70° Celsius - 5 adjustment units

Heater Sensor Limit:

125° Celsius (heater sensor no. 1)

Temperature Sensor Limit:

140° Celsius (heater sensor no. 1)

Temperature Indicator:

Maximum 110° Celsius (RAL point sensor no. 2)

Heat Cycle Limit:

240 minutes or 4 hours

Lighting:

Maximum 60W - dimmable 10% adjustment units

Ambient Temperatures:

-20° to plus 60° Celsius

Outdoors:

Protectives enclosure required (splash proof)

Control Pad Dimension:

200x135mm (7.87x5.3inch)

Item dimension (L x W x H):

250x80x195mm (9.8x3.15x7.68inch)


Features of External Bio Digital Wall Mounted Controller - BD7012

  • Thermostat

  • Max 4 hours

  • Light switch

  • Indicator light

  • For use with FIN and Club heater models

  • Has °F or °C display settings

  • Adjusts time duration, temperature, and controls room light
